detail product
Tuk Tuk High Quality Electric Tricycle
- Product Code: L-GN60
Tags: tuk tuk high quality electric tricycle, l-gn60, electric vehicle parts, tuk tuk electric tricycle
| Model No.: | L-GN60 |
| Overall size： | 3400*1350*1790 |
| Passenger Capacity: | 1 Driver+ 6 Passengers (max 7-8 peoples |
| Dynamical System / Motor: | 4000W AC motor |
| Controller: | Special 4000W AC controller |
| Rear Axle: | Independent CV joint suspention 220 oil drum brake |
| Shock absorber system: | F:swing arm suspension fork R: Independent CV(constant velocity) joint suspention |
| Brake System: | Front:180mm oil drum brake Rear: 220mm oil drum brake |
| Battery: | Lithium battery (optional) 72v/150ah |
| WheelBase | 2740mm |
| Axle Width | 1150mm |
| Ground Clearance | 300mm |
| Climbing Ability | 25 degree |
| Load Capacity: | 1100kg |
| Max Speed: | 45-60 km/h |
| Endurance Mileage | 80-150km Depends on the battery |
| Charging Time： | 8 Hours |
| Colors and logo | Grey,Blue,Yellow,Red or Customized color / accept customized logo |
| Tires: | Front 125-65-12, rear:125-65-12 |
| Net Weight: | 385 kg without battery |
| 40ft Container QTY: | 26sets/40HQ（CKD） |
| 40ft Container QTY: | 16 sets/40HQ（SKD） |
